EGM-5 Operation Manual V. 1.04 17 support@ppsystems.com
System Power
The EGM-5 has an internal, rechargeable lithium ion battery pack capable of providing continuous power
to the instrument for up to 16 hours. The EGM-5 is supplied with an external AC power adapter to charge
and/or power the EGM-5.
Battery Specification
• Type: Rechargeable Smart Lithium Ion Battery Pack
• Power: 7.2V, 8.7Ahr, 63Whr
Note, if the EGM-5 is used with external sensors/chambers it will reduce the battery life depending on the
probe connected.
A dead battery (0% capacity) can be fully recharged in approximately 4-5 hours using the power
supply/charger supplied by PP Systems.
To check the battery status, simply power up the instrument and observe the battery capacity next to the
flashing heartbeat in the upper left hand corner of the display (see below).
Power Supply/AC Adapter Rating:
• Input: 100-240 VAC, 50-60 Hz, 1.0A
• Output: 12 VDC, 3.3A
Mains Charger/Power Supply
