EGM-5 Operation Manual V. 1.04 32 support@ppsystems.com
Graphical Display Screen
♥ (Heartbeat)
Pulses on and off to indicate that the system is powered and operating. Press to
return to normal 1 second display updates.
56%
Percentage of battery life remaining.
Record
Saves current data as a marked record in the USB Memory stick and also sends
the record to the host and WiFi ports
98%
Percentage of absorber column remaining.
Z Button
Initiates a zero.
CO2 Button
Current measurement of CO
2
concentration in ppm, and when pressed changes
graphed parameter to CO
2
H
2
O Button
Current measurement of H
2
O partial pressure in mb, and when pressed changes
graphed parameter to H
2
O (0 - 30 mb)
O
2
Button
Current measurement of O
2
concentration in %, and when pressed changes
graphed parameter to O
2
(0-100%)
0-2000 ppm
Y-axis range and units (CO
2
concentration).
3 min
X-axis time; fixed value of 3 minutes.
Left Arrow
Displays the previous Measurement Mode screen (the probe screen).
Status Box
Any information or error messages are displayed here.
Right Arrow
Completes the rotation of the Measurement Mode screens and returns to the
Measure screen..
The moving horizontal line below the CO
2
concentration value indicates where on the timeline the graph
data is being displayed. The y-axis maximum (CO
2
concentration) is the number located under the graph
on left side (for example, 10000 ppm). The X-axis maximum (time) is the number located under the graph
on the right side. The x-axis maximum is a fixed value of about 4 minutes.
The maximum CO
2
value can be set in the Graph Settings screen. See Graph Settings on page 45 for
more details.
