EGM-5 Operation Manual V. 1.04 47 support@ppsystems.com
Determines the measurement data format. All data formats are available (M1-
M6). The default is M3. See the Measure Format Settings Table on page 93
Determines the time interval, in seconds, in which data will be transmitted. A
value of 0 disables automatic transmission of measurement data, but zero
operations and Process operations will still be reported. The maximum value
is 3600 seconds (1 hour). Default is 1 second.
Returns to the Settings 3 Menu.
Host Measure Format
To change the Host Measure Format, select the button to the right of the “Format:” text. The Measure
Format Settings screen will be displayed with the current selection indicated.
Measure Format Settings
Six Measure Format Settings are available. See the Measure Format Settings Table on page 93 for more
information.
Press the desired setting and then the Back button and the Measure Format Settings Menu will return
with the updated format setting in the button box.
Host Measure Interval
To change the Host Measure Interval, select the button to the right of the “Interval:” text. The numerical
keypad will appear allowing a new number to be entered. See numerical keypad description under Zero
Time on page 36 for more details.
Press the “Back” button to return to the Settings 3 Menu.
