EGM-5 Operation Manual V. 1.04 95 support@ppsystems.com
• Record No: 1-65535
• CO
2
(ppm): CO
2
reading in parts per million (ppm = µmol mol
-1
)
• Air Pressure (mb): Atmospheric pressure
• Flow Rate (cc/min): Rate of flow.
• H
2
0 (mb): H
2
O reading
• H
2
0 Sensor Temperature (°C): Temperature of the gas sample.
• O
2
(%): O
2
reading
• System Error: Displays error code message. (See Error Messages table)
• Aux Voltage (volts): Analog Output Voltage.
• PAR: (ppm = µmol m
2
s
-1
)
• Tsoil: Temperature (°C)
• Tair: Temperature (°C)
• RH: Percent Humidity
• Parameter 1 (See Process Data Fields on page 91)
• Parameter 2 (See Process Data Fields on page 91)
• Parameter 3 (See Process Data Fields on page 91)
• Parameter 4 (See Process Data Fields on page 91)
• Parameter 5 (See Process Data Fields on page 91)
M6
M6 is the raw format containing raw data (A/D values) from the IRGA. It is comma
delimited.
An example is:
M6, 44572, 50675, 17603, 17600, 37340, 50292,0x0040<CR>
The format is as follows:
• M6: Specifies the data format.
• CO
2
A/D Counts: Proportional to the CO
2
reading.
• Air Pressure A/D Counts: Proportional to the atmospheric pressure
reading.
• Temperature Probe1 A/D Counts: Proportional to the temperature of probe
1.
• Temperature Probe2 A/D Counts: Proportional to the temperature of probe
2.
• Lamp A/D Counts: Proportional to lamp current.
• Last Zero CO
2
: Reports A/D counts of the last zero value.
• System Error: Displays error code message. (See Error Messages table)
