Illustrations of Printer Components
233
Item
No.
Part No. Description Notes
1 164295-001 Shuttle Cover (Shroud Assembly, Air)
2 Ref Screw, Captive (2) 10-24x.62 with O-ring,
.125x.250x.06
3 Ref Screw, Thread-forming (2) 6-32x.25 and #6 flat washer
4 Ref Barrier Shield
5 154286-001 Paper Path
6 152284-901 Anti-Static Brush Kit
7 154073-001 Power Supply Shield Taped to card cage along
upper edge
8 108664-903 Belt, Timing, .080 Pitch, 100 Teeth,
.500 Wide
Paper Feed Belt
9 153488-001 Platen/Paper Feed Cover Kit Paper Feed Belt Cover
shown
10 153528-901 Paper Scale
To Next Page
