Printronix P5000 - Page 234

234
Chapter 5 Section II: Illustrated Parts Lists
Figure 38. Card Cage Detail, Pedestal Models
From Figure 37, page 232.
Rotated 180 degrees.
5
A
To IEC 320 AC
Power Input
(Connector
J301, White
Wire)
To Connector P1
(Black Wire)
To IEC 320 AC Power
Input (Connector J301,
Black Wire)
To Connector P1
(White Wire)
1
2
3
4
6
