Printronix P5000 - Page 237

Illustrations of Printer Components
237
Item
No.
Part No. Description Notes
1 174550-901
174549-901
174551-901
Hammer Bank Cover Assy, 500
Hammer Bank Cover Assy, 1000
Hammer Bank Cover Assy, 1500
P5X05B
P5X10, P5X03H
P5X15, P5X06H
2 174957-901
175863-901
174958-901
174959-901
175615-001
175614-001
174965-901
175860-901
174966-901
174967-901
175609-001
175613-001
Shuttle Frame Assembly
Shuttle Frame Assembly
Shuttle Frame Assembly
Shuttle Frame Assembly
Shuttle Frame Assembly
Shuttle Frame Assembly
Hammer Spring Assembly Field Kit
Hammer Spring Assembly Field Kit
Hammer Spring Assembly Field Kit
Hammer Spring Assembly Field Kit
Hammer Spring Assembly
Hammer Spring Assembly
P5X05B
P5X05B-12
P5X10
P5X15
P5X03H
P5X06H
P5X05B
P5X05B-12
P5X10
P5X15
P5X03H
P5X06H
3 157102-901
176096-001
Power Supply PCBA, V4
Power Supply PCBA, P5X10, PFC P5X05B and P5X10 only
4 Ref P101 Cable Connector
5 Ref Cable Assembly, AC-In, Power Supply Part of Field Kit, AC Assy,
153502-901
6 157450-901
171692-901
Controller Board Assy, CMX V5.5
Controller Board Assembly, CFX V1
All except H-Series
Only P5X03H and P5X06H
7 202362-901 Connector Kit (P106/P107) P106, Motor Sensor, Left
8 Ref Hammer Bank Logic Cable Assembly
9 Ref Shuttle Motor Cable Assembly
10 Ref Hammer Bank Power Cable Assembly
11 202362-901 Connector Kit (P106/P107) P107, Motor Sensor, Right
12 152439-901 Centronics I/O Cable Assembly
13 Ref Control Panel Cable Assembly
14 150399-901 Clamp, Shaft, Receiving
15 Ref Screw, Captive, Power Supply (3)
16 202417-001 SIMM, Flash Memory, 4 MB
17 202412-001 SIMM, DRAM, 4MB, 1Mx32, 70 NS,
72 Pin
18 Ref Security Module
