Chapter 5 Section II: Illustrated Parts Lists
Figure 40. Magnetic Pickup (MPU) and Extension Spring
CAUTION:
Make sure the MPU
cable does not touch
the extension spring
after cable
connection.
5
0.010 ± .001 inch (0.254 ± .025 mm)
Spring Lug (Do not
remove grease)
Spring Lug (Do not
remove grease)
2
1
3
4
A
A
6
