Illustrations of Printer Components
239
Item
No.
Part No. Description Notes
1 150281-901 MPU Assembly
2 Ref Bracket, MPU Part of item 1
3 Ref Screw, Socket Cap 6-32x.38
4 153537-901 Extension Spring
5 Ref MPU Cable Connector (P03)
6 176507-001 Anti-Rotation Spring Constraint Used only on model P5X08H
and P5220S, which are not
covered in this manual
To Next Page
