Illustrations of Printer Components
241
Item
No.
Part No. Description Notes
1 Ref Screw, Socket Cap, 6-32x.312 Trilob
(Self-Tapping) (2)
2 173130-001 Plate, Tractor Shaft, Left
3 151944-001 Bearing, Ball, Sealed
4 155182-901 Paper Support (2)
5 204155-001 Tolerance Ring,.37X.25,.006 THK,SS
6 173272-001 Splined Shaft Assembly
7 Ref Screw, Socket Cap, 6-32x.312 Trilob
(Self-Tapping)
8 173217-001 Plate, Tractor Shaft, Right
9 173137-001 Support Shaft
10a
10b
173276-901
173929-901
Tractor Set, RH & LH
Tractor Set, Ironer Roller Installed at factory on
models with power stacker
11 Ref Right Side Plate
12 Ref Left Side Plate
To Next Page
