Illustrations of Printer Components
247
Item
No.
Part No. Description Notes
1 142013-901 Circuit Breaker
2 Ref IEC 320 AC Power Connector Connector J301
3 Ref Chassis Ground Stud
4 Ref Connector P1 To power supply board
connector J1 AC
5 Ref Cable Assembly, AC-In, Power Supply Part of Field Kit, AC Assy
153502-901
To Next Page
