Printronix P5000 - Page 246

246
Chapter 5 Section II: Illustrated Parts Lists
Figure 44. Circuit Breaker, Cabinet Models
To IEC 320 AC Power
Input (Connector J301,
White Wire)
To Connector P1
(Black Wire)
To IEC 320 AC Power
Input (Connector J301,
Black Wire)
To Connector P1
(White Wire)
A
B
A
B
See inside detail below.
(Card cage fan and
power supply board
removed for clarity.)
4
5
3
2
White Wire
Black Wire
Black Wire
1
White Wire
