Illustrations of Printer Components
245
Item
No.
Part No. Description Notes
1 150261-901 Card Cage Fan Assembly Air flow is into card cage
2 Ref Screw, w/Lock Washer (3) Two 6-32x1.75 on bottom,
One 6-32x0.50 on top left
3 152415-901
170172-001
Switch Assembly, Paper Detector
Field Kit, Slotted Black Back Form
Switch
Optional switch assembly
used with black back forms
4 Ref Screw, Thread-forming, 6-32x.375 (2) Part of item 3
5 152299-901 Motor Assembly, Platen
6 Ref Screw, Hex w/Lock Washer, 10-24x.50
(2)
Part of item 18
7 163597-901 Ribbon Guide Kit
8 Ref Washer, Flat #4 Part of item 7
9 Ref Screw, w/Lock Washer, 4-40x.38 Part of item 7
10 Ref Screw, w/Lock Washer, 10-32x.50 (2) Part of item 5
11 Ref Shield, Card Cage Fan
12 154071-901 Motor Assembly, Ribbon
13 Ref Screw, Hex w/Lock Washer (2) 6-32x.50
14 Ref Washer, Flat #6 (2)
15 150868-001 Ribbon Hub Kit
16 Ref Screw, w/Lock Washer (2) 6-32x1.25
17 152416-901 Hammer Bank Fan Assembly Air flow is up
18 154068-901 Motor Assembly, Paper Feed
To Next Page
