Printronix P5000 - Page 344

344
Appendix E Removing The Power Stacker
14. Remove four cables from the stacker control panel, and remove the
stacker control panel. (Figure 69.)
Figure 69. Removing Cables from the Stacker Control Panel
Logic Cable (P104)
Power Cable (P106)
Frame Cable (P102)
Rail Cable (P107)
A
A
Remove the
Tie Wrap
