Screws and cage nuts attach
the Vess to the rack posts
Handles mount outside the rack post
Mounting rails mount outside the rack post
System installed in rack
Vertical rack post
Secure to rack
4. Secure the enclosure to the rack.
• Use screws and nuts to lock the unit in to place in the rack.
17
Promise Technology
Hardware Setup
