Placing the Vess system onto the rack rails
Rails installed and
tightened
Handles
Rail ends attach on the out-
side of the front and rear rack
posts
Rail ends aach to the outside of each post
3. Place the Vess onto the rails.
• At least two persons are required to safely lift the system.
• Lift the Vess itself. Do not lift the system by its brackets.
Warning
Two persons are needed to safely place the
unit onto the rails.
DO NOT lift the unit by the handles
16
Promise Technology
Vess R3600 / Vess J3600 Product Manual
