QLS-4100 Xe D-5
10 Select the appropriate Printer Mode.
DUAL – Select this option for parallel and serial port connection.
LPT – Select this option for parallel-only connection.
COM – Select this option for serial-only connection.
TCP/IP – Select this option for an ethernet connection.
11 Select the appropriate Parallel Port, Serial Port, and TCP/IP settings as
necessary.
Note: Custom QuickLabel supports parallel ports LPT1 and LPT2 and
serial ports COM1 and COM2. The maximum supported baud rate for
the serial port is 38,400 baud. Hardware handshaking (DTR/DSR) is
always used by default.
12 Click OK when all printer settings have been made.
