4-6 Keypad controls and menus
Operation Menu Options are available in a Pause state only.
Pull Back Requires special hardware. Contact QuickLabel for
more information on this function.
Label Reprint Reprints up to 999 copies of the last label printed, if
using the Windows print driver.
Synchronize Labels Synchronizes labels when using printer/applicator
or Print & Peel.
Ribbon Menu Options are available in a Pause state only.
Ribbon Type Selects printhead intensity tailored to a specific
media type. Possible values are Standard and
Resin/Synthetic.
Drop/Lift Adjust Adjust the drop and lift point for printheads 1 – 4.
Possible values are 0 to +40 mm.
Ribbon Sensor Used by QuickLabel technicians when performing
factory diagnostics. Possible values are Enabled
and Disabled, but in general use, the sensor should
always be enabled.
Communications
Menu
Options are available in a Pause state only.
Data Port Selects the data input interface used by the printer.
Possible values are Parallel, Serial, or Ethernet.
Parallel Mode Specifies the mode of connection for the parallel
port. Possible values are Auto or Standard.
RS232 Baud Rate Specifies a baud rate for the RS232 serial port.
Possible values are 4800, 9600, 19200, or 38400.
RS232 Handshaking Specifies a handshaking method for the RS 232
serial port. Possible values are Hardware or
XON/XOFF.
TCP/IP Address Specifies the IP address of the printer for ethernet
purposes.
