5. START-UP
• Plug the power adapter to a socket, next connect the connector to port located at
the back of the housing.
• Press key located in the top right hand corner of the panel.
• Upon completed start-up, the home screen is displayed automatically.
• The moisture analyzer runs with no operator logged in. In order to start operation it
is necessary to carry out logging procedure (for detailed logging procedure read
later sections of this service manual).
6. OPERATION PANEL
Press to switch the moisture analyzer ON/OFF
Press to zero the moisture analyzer
Press to tare the moisture analyzer
Press to confirm modifications/ to send the weighing result to a printer
or a computer
Function key <Esc>, press to abort parameter modifications or exit to
previous menu level
Function key <Home>, press to exit to home screen
Programmable proximity sensors, press to enable operation of freely
selected functions
