7. HOME SCREEN
7.1. Weighing Result Window
The home screen can be divided into 3 sections:
• Top section displaying data on active working mode (pictogram and name),
metrologically important data and button enabling selection of functions available for
a particular working mode:
The top bar displays the following information:
Working mode name and symbol.
Symbol informing that wireless communication is on.
Symbol informing that communication with a USB flash
drive is on.
Symbol informing that PC keyboard is connected.
Symbol informing that printer is connected via USB.
Symbol informing that communication with a PC
computer is on.
Symbol informing that data is saved to moisture
analyzer memory.
Symbol informing that the moisture analyzer connects
with E2R system.
Symbol informing that the weighing profile is active.
• Section presenting the weighing result:
• Section comprising supplementary information on currently performed operations,
and function buttons:
