• Printout interval
Parameter enables setting printout frequency for continuous transmission.
Printout frequency is set in seconds, with 0.1s accuracy.
Time values range between 1000s. and 0.1 s. The setting is valid for
continuous transmission in calibration unit and in current unit activated by
means of the moisture analyzer. It is also valid for continuous transmission
activated by a command sent from a computer.
22.2. Printer
Submenu <Printer> enables you to select a port to which data is to be sent upon pressing
key. Content of sent data is set in <PRINTOUTS/GLP PRINTOUTS> parameter.
Procedure:
• Press button.
• Enter <PERIPHERALS> menu.
• Enter <PRINTER> submenu.
o set moisture analyzer parameters related to integration with the printer: <PORT> to
which the printout is to be sent upon pressing key (printer connected).
Available options:
Caution: In order to set USB Free Link instead of USB select any other port (e.g. none,
COM1, etc.) and next select USB Free Link port. Analogously when changing USB Free Link
to USB.
COM 1 – RS 232 port, the one to which a printer is connected
USB – USB 1 port, type A, for connecting a PCL or EPSON printer,
Ethernet – port for transferring data from moisture analyzer to a dedicated
RADWAG software, e.g. PW-WIN, operated on a computer connected to a
moisture analyzer via network.
PENDRIVE – USB 1 port, type A, for connecting USB flash drive. PENDRIVE
option requires setting format for saved file. You can save the data in the following
formats: *.txt format (text file that can be opened on the computer using Notepad),
or *.csv format (file that can be opened using Excel).
WIFI – port intended to enable sending data to RADWAG manufactured software
PW WIN (opened on computer connected to moisture analyzer via Wi-Fi), to printer
featuring Wi-Fi port or to network printer.
USB PC – USB 2 port, type B, for connecting a computer with a dedicated
RADWAG software, e.g. PW-WIN.
USB FREE LINK - USB port, type B, for connecting a computer. Tool for entering
data, it functions as a keyboard. Upon proper modification of non-standard printout
and sending proper command from the computer, or upon pressing ENTER key
located on the operation panel, the data from non-standard printout is entered
directly to computer programs, e.g. Excel, Word, Notepad etc.
Select <USB FREE LINK> port and configure its settings in order to enable correct
compatibility of the moisture analyzer with computer programs:
SPREADSHEET - value YES --.-- - compatibility with Excel type program, (.) dot
is used as decimal point while sending the mass value
