Remote Control
R&S
®
FPC
240User Manual 1178.4130.02 ─ 07
Parameters:
<State> ON | 1
Turns on the third order intermodulation measurement.
OFF | 0
Performs a basic spectrum measurement.
*RST: OFF
Example: //Measure the TOI
CALC:MARK:FUNC:TOI ON
Manual operation: See "Third Order Intermod." on page 361
19.12.1.4
Occupied Bandwidth
The following remote commands are exclusive to the occupied bandwidth measure-
ment.
CALCulate<n>:MARKer<m>:FUNCtion:OBW:BANDwidth.................................................. 240
CALCulate<n>:MARKer<m>:FUNCtion:OBAN:BANDwidth.................................................240
CALCulate<n>:MARKer<m>:FUNCtion:OBW:BANDwidth:PCT...........................................240
CALCulate<n>:MARKer<m>:FUNCtion:OBAN:BANDwidth:PCT......................................... 240
CALCulate<n>:MARKer<m>:FUNCtion:OBW:BANDwidth <ChannelBW>
CALCulate<n>:MARKer<m>:FUNCtion:OBAN:BANDwidth <ChannelBW>
This command defines the channel bandwidth for occupied bandwidth measurements.
Prerequisites for this command
●
Turn on occupied bandwidth measurement (CALCulate<n>:MARKer<m>:
FUNCtion:POWer:SELect).
Suffix:
<n>, <m>
.
irrelevant
Parameters:
<ChannelBW> <numeric value>
*RST: 3.84 MHz
Default unit: Hz
Example: //Define a channel bandwidth
CALC:MARK:FUNC:OBW:BAND 1 MHZ
Manual operation: See "Channel Bandwidth" on page 366
CALCulate<n>:MARKer<m>:FUNCtion:OBW:BANDwidth:PCT <Percentage>
CALCulate<n>:MARKer<m>:FUNCtion:OBAN:BANDwidth:PCT <Percentage>
This command defines the percentage of the total power that defines the occupied
bandwidth.
Suffix:
<n>, <m>
.
irrelevant
Remote Commands of the Spectrum Application
