R&S FPC Series User Manual

Remote Control
R&S
®
FPC
241User Manual 1178.4130.02 ─ 07
Parameters:
<Percentage> <numeric value>
Range: 10 to 99.9%
*RST: 99%
Example: //Define power percentage
CALC:MARK:FUNC:OBW:BAND:PCT 95
Manual operation: See "% Power Bandwidth" on page 367
19.12.1.5 TDMA Power
The following remote commands are exclusive to the TDMA power measurement.
Commands to configure TDMA power measurements described elsewhere.
●
Sweep time:
[SENSe:]SWEep:TIME
CALCulate<n>:MARKer<m>:FUNCtion:TDMA:BURSt....................................................... 241
CALCulate<n>:MARKer<m>:FUNCtion:TDMA:BURSt <BurstLength>
This command defines the burst length of the TDMA signal.
Prerequisites for this command
●
Turn on TDMA power measurement (CALCulate<n>:MARKer<m>:FUNCtion:
POWer:SELect).
Suffix:
<n>, <m>
.
irrelevant
Parameters:
<BurstLength> <numeric value>
The value range depends on the current sweep time.
*RST: 470 us
Default unit: s
Example: //Define the burst length
CALC:MARK:FUNC:TDMA:BURS 80 US
Manual operation: See "Burst Length" on page 365
19.12.1.6 Harmonic Distortion
The following remote commands are exclusive to the harmonic distortion measure-
ment.
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:DISTortion?........................................ 242
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:LIST?.................................................242
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:NHARmonics......................................243
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics:PRESet..............................................243
CALCulate<n>:MARKer<m>:FUNCtion:HARMonics[:STATe].............................................. 244
Remote Commands of the Spectrum Application
