Remote Control Fundamentals
R&S
®
NRP2
187User Manual 1173.9157.02 ─ 03
Menu item in manual control SCPI command in short form
Windows→Analog Meter... →Right
DISP[1..4]:MET:UPP
DISP[1..4]:ANAL:UPP
Measurement→Function...→Primary Channel
Measurement→Function...→Secondary Chan-
nel
Measurement→Function...→Function
CALC[1..8]:MATH:EXPR
Measurement→Function...→Unit
UNIT:POW and UNIT:POW:RAT
Measurement→Function...→Auxiliary Value
= Max
= Min
= Max - Min
DISP[1..8]:AVAL
CALC[1..8]:MAX:DATA?
CALC[1..8]:MIN:DATA?
CALC[1..8]:PTP:DATA?
Measurement→W / dBm / dBµV
UNIT:POW
Measurement→dB / Δ% / 1
UNIT:POW:RAT
Measurement→Rel On / Off
Measurement→Rel Reset
CALC[1..8]:REL:STAT
and
CALC[1..8]:REL:AUTO ONCE
Measurement→Ref. Val...→Ref. Value
CALC[1..8]:REL
Measurement→Ref. Val...→Ref. Value→Reset
(Result→Ref)
CALC[1..8]:REL:AUTO ONCE
Measurement→Limits...→Warning Sound
CALC[1..8]:LIM:BEEP
Measurement→Limits...→Upper Limit On
CALC[1..8]:LIM:UPP:STAT
Measurement→Limits...→Upper Limit
CALC[1..8]:LIM:UPP[:DATA]
Measurement→Limits...→Lower Limit On
CALC[1..8]:LIM:LOW:STAT
Measurement→Limits...→Lower Limit
CALC[1..8]:LIM:LOW[:DATA]
Measurement→Aux Val Reset
CALC[1..8]:EXTR:RES
File→Preset
SYST:PRES or *RST
File→Setup Recall...→Recall
*RCL
File→Setup Save...→Save
*SAV
File→Setup Save...→Edit Name
MEM:STAT:DEF
File→Standard Recall...→Preserve Window
Settings
SYST:STAN:PWS
File→Standard Recall...→Trigger Source
SYST:STAN:TRIG:SOUR
File→Standard Recall...→Recall
SYST:STAN:PRES
File→Sensor Info...
SYSTem:SENS[1..4]:INFO?
File→System Info...
SYSTem:INFO?
File→Window Name
DISP:NAME
Correspondence between Remote Control and Manual Control
