Remote Control Fundamentals
R&S
®
NRP2
188User Manual 1173.9157.02 ─ 03
Menu item in manual control SCPI command in short form
System→Remote... →GPIB→GPIB Address
SYST:COMM:GPIB:ADDR
System→I/O... →Out 1 1234
OUTP:REC1:FEED
or
OUTP:TTL:FEED
System→I/O... →Out 1→Analog
OUTP:REC1:STAT ON
System→I/O... →Out 1→Pass/Fail
OUTP:TTL:STAT ON
System→I/O... →Out 1→Off
OUTP:REC1:STAT ON
OUTP:TTL:STAT ON
System→I/O... →Out 1→0 V Equivalent (if Ana-
log is selected)
OUTP:REC1:LIM:LOW...
System→I/O... →Out 1→3 V Equivalent (if Ana-
log is selected)
OUTP:REC1:LIM:UPP...
System→I/O... →Out 1→Fail (if Pass/Fail is
selected)
OUTP:TTL:FAIL HIGH
and
OUTP:TTL:HVOLT
System→I/O... →Out 1→Pass (if Pass/Fail is
selected)
OUTP:TTL:FAIL HIGH
and
OUTP:TTL:LVOLT
System→I/O... →I/O 2 1234
OUTP:REC2:FEED
System→I/O... →I/O 2→Analog Out
OUTP:REC2:STAT ON
System→I/O... →I/O 2→ATrigger In
OUTP:REC2:STAT OFF
System→I/O... →I/O 2→A0 V Equivalent (if Ana-
log Out is selected)
OUTP:REC2:LIM:LOW...
System→I/O... →I/O 2→A3 V Equivalent (if Ana-
log Out is selected)
OUTP:REC2:LIM:UPP...
System→Errorlist
DISP:ERR:STAT
SYST:ERR:EXT:STAT
SYST:ERR?
System→Test... →Sensor ABCD / Init. Test
SYST:SENS[1..4]:TEST?
*TST?
System→Power Ref
OUTP:ROSC
System→Display Update
DISP:UPD
System→Misc...→Beeper→Key
SYST:BEEP:NOT:KEY
System→Misc...→→Overload
SYST:BEEP:NOT:OVER
System→Misc...→Brightness
DISP:ILL
DEL/1TRIG If the "Single" check box was enabled in the Trace mode,
pressing DEL/1TRIG sends a *TRG to the sensor.
(PRE)SET Opens the File menu
Correspondence between Remote Control and Manual Control
