Remote Control - Commands
R&S
®
NRP2
229User Manual 1173.9157.02 ─ 03
string Meaning
"(SENSn+SENSm)"
The calculate block outputs the sum of the measured values of sensor n and
sensor m.
"(SENSn /SENSm)"
The calculate block outputs the quotient of the values measured by sensor n
and m.
"SWR(SENSn,SENSm)"
SENSnSENSm
SENSnSENSm
/1
/1


If sensor n measures the forward power of a wave and sensor m the reflected
power, the calculate block outputs the standing wave ratio of this wave. The
output unit is set to percent (UNIT:RAT PCT).
"REFL(SENSn,SENSm)"
SENSnSENSm /
If sensor n measures the forward power of a wave and sensor m the reflected/
transmitted power, the calculate block outputs the reflection coefficient/trans-
mission factor of a DUT. The output unit is set to percent (UNIT:RAT PCT).
"RLOS(SENSn,SENSm)"
SENSnSENSm /log20
10

If sensor n measures the forward power of a wave and sensor m the reflected/
transmitted power, the calculate block outputs the return loss/transmission loss
of a DUT. This function principally supplies the same result as the (SENSn/
SENSm) function. The difference is that the output unit is automatically set to
dB.
(UNIT:RAT DB).
Parameters:
<string> string
The *RST values depend on the selected channel:
CALC1:MATH: "(SENS1)",
CALC2:MATH: "(SENS2)",
CALC3:MATH: "(SENS3)",
CALC4:MATH: "(SENS4)",
CALC5:MATH: "(SENS1)",
...
CALC8:MATH: "(SENS1)".
CALCulate<[1]..8>:
MATH[:EXPRession]:CATalog?
Lists all supported calculation functions. All functions are sent in the form of strings which
are allowed as parameters for the CALCulate<[1]..8>:MATH:EXPRession com-
mand.
Usage:
Query only
CALCulate (Configuration of Calculate Blocks)
