Remote Control - Commands
R&S
®
NRP2
240User Manual 1173.9157.02 ─ 03
Parameters:
<avalue> NONE | NORMal | EXTRemes | STATistics
NONE
No additional information about the measured values is displayed.
NORMal
The display is a function of the SENS:FUNCtion of the measure-
ment mode of the primary channel and the CALC:FEED setting.
Primary channel in the trace mode:
The top line displays the frequency of the primary channel. The
two lower lines and the main measured value window display
Average, Peak and PeakToAverage. CALC:FEED determines
which of the three quantities is displayed in the main measured
value window. The other two quantities are displayed on the right-
hand side, below the frequency.
Primary channel not in the trace mode:
Only the frequency of the primary channel and, if applicable, the
frequency of the secondary channel are displayed.
EXTReme
Minimum, maximum and peak-to-peak (maximum to minimum) of
all measured values displayed since the last CALC:EXTR:RES,
PowerOn or AuxVal Reset are shown (manual operation). With
logarithmic units, the peak-to-peak value equals the quotient of the
measured values converted into linear units.
STATistic
The mean value, the standard deviation and the number of all
measured values displayed since the last CALC:EXTR:RES, Pow-
erOn or AuxVal Reset are shown (manual operation) (see also 
CALCulate:...:DATA?).
*RST:
NONE
DISPlay[:WINDow]<[1]..4>:FORMat <display_mode>
Selects the display mode for measured data.
