Remote Control - Commands
R&S
®
NRP2
223User Manual 1173.9157.02 ─ 03
CALCulate<[1]..4>:STATistics:MARKer:HORizontal:DATA?...............................................233
CALCulate<[1]..4>:STATistics:MARKer:VERTical:POSition[:Y]...........................................233
CALCulate<[1]..4>:STATistics:MARKer:VERTical:DATA[:POWer]?.....................................233
CALCulate<[1]..4>:STATistics:POWer:AVG:DATA?...........................................................234
CALCulate<[1]..8>:COUNt:DATA?
Queries the number of measured values that are included when the mean value and
standard deviation are calculated (in the above formulas referred to as N, see Mean value
of all measured values and Standard deviation σof all measured values).
Usage: Query only
CALCulate<[1]..8>:DATA?
With this command the current output value of a calculate block can be queried.
The unit is the current unit of the measured result.
Possible Units: W | DBM | DBUV | DPCT | DB | O
Usage:
Query only
CALCulate<[1]..8>:EXTRemes:RESet
The R&S NRP2 stores the maximum and minimum values for each calculate block. The
current measured value is stored with CALC[1..8]:EXTR:RES as the new minimum
and maximum value. The extreme values can be queried with
CALC[1..8]:MIN:DATA? and CALC[1..8]:MAX:DATA?.
Usage:
Event
CALCulate<[1]..8>:FEED<[1]|2> <feed>
The sensors connected with the calculate block via the primary and secondary channel
can yield differently processed data: peak value, average value, peak-to-average value
or even a measurement sequence, as is the case in the Trace mode. The CALC:FEED
determines which of this data is to be processed by the calculate block. Depending on
the measurement mode, the following settings are possible:
CALCulate (Configuration of Calculate Blocks)
