Remote Control - Commands
R&S
®
NRP2
222User Manual 1173.9157.02 ─ 03
channels (primary and secondary channel). The available sensors (1 to 4, depending on
device configuration and connected sensors) can be assigned to the channels. With the
aid of a selectable function (CALC:MATH), the channels can be processed together.
Suffix <1..8>behind the CALCulate key word denotes the CALCulate block. Each
CALCulate block is assigned a measurement window. The R&S R&S NRP2 can display
up to four windows with measurement results.
In the digital "Dig" and digital/analog "D&A" mode CALCulate blocks 1 to 4 are associ-
ated with the windows 1 to 4. In the graphical "Graph" mode, the CALCulate blocks 1
to 8 are associated with the measurement windows and the traces as follows:
Calculate block Window Trace
1...4 1...4 1
5...8 1...4 2
Suffix <1|2> behind the FEED key word word assigns a sensor to the primary or secondary
channel.
CALCulate<[1]..8>:COUNt:DATA?...................................................................................223
CALCulate<[1]..8>:DATA?..............................................................................................223
CALCulate<[1]..8>:EXTRemes:RESet..............................................................................223
CALCulate<[1]..8>:FEED<[1]|2>......................................................................................223
CALCulate<[1]..8>:LIMit:BEEP........................................................................................225
CALCulate<[1]..8>:LIMit:CLEar[:IMMediate]......................................................................225
CALCulate<[1]..8>:LIMit:CLEar:AUTO..............................................................................225
CALCulate<[1]..8>:LIMit:FAIL?........................................................................................225
CALCulate<[1]..8>:LIMit:FCOunt?....................................................................................226
CALCulate<[1]..8>:LIMit:LOWer[:DATA]...........................................................................226
CALCulate<[1]..8>:LIMit:LOWer[:DATA]:POWer................................................................226
CALCulate<[1]..8>:LIMit:LOWer[:DATA]:RATio.................................................................226
CALCulate<[1]..8>:LIMit:LOWer:STATe............................................................................227
CALCulate<[1]..8>:LIMit:STATe.......................................................................................227
CALCulate<[1]..8>:LIMit:UPPer[:DATA]............................................................................227
CALCulate<[1]..8>:LIMit:UPPer[:DATA]:POWer................................................................227
CALCulate<[1]..8>:LIMit:UPPer[:DATA]:RATio..................................................................228
CALCulate<[1]..8>:LIMit:UPPer:STATe............................................................................228
CALCulate<[1]..8>:MATH[:EXPRession]...........................................................................228
CALCulate<[1]..8>:MATH[:EXPRession]:CATalog?...........................................................229
CALCulate<[1]..8>:MAXimum:DATA?..............................................................................230
CALCulate<[1]..8>:MINimum:DATA?................................................................................230
CALCulate<[1]..8>:MEAN:DATA?....................................................................................230
CALCulate<[1]..8>:PTPeak:DATA?..................................................................................230
CALCulate<[1]..8>:RELative[:MAGNitude]........................................................................230
CALCulate<[1]..8>:RELative[:MAGNitude]:AUTO..............................................................231
CALCulate<[1]..8>:RELative:POWer[:MAGNitude].............................................................231
CALCulate<[1]..8>:RELative:RATio[:MAGNitude]..............................................................232
CALCulate<[1]..8>:RELative:STATe.................................................................................232
CALCulate<[1]..8>:SDEViation:DATA?.............................................................................232
CALCulate<[1]..4>:STATistics:MARKer: HORIzontal:POSition[:X][:POWer] .........................233
CALCulate (Configuration of Calculate Blocks)
