Remote Control - Commands
R&S
®
NRP2
231User Manual 1173.9157.02 ─ 03
Table 6-11: Output unit of measured value of calculate block
CALC:MATH? CALC:REL:STAT OFF CALC:REL:STAT ON
"(SENSn)"
DBM | W | DBUV DB | DPCT | O
"(SENSn-SENSm)"
DBM | W | DBUV DB | DPCT | O
"(SENSn+SENSm)"
DBM | W | DBUV DB | DPCT | O
"(SENSn/SENSm)"
DB | DPCT | O DB | DPCT | O
"SWR(SENSn,SENSm)"
O -
"REFL(SENSn,SENSm)"
O -
"RLOS(SENSn,SENSm)"
DB -
The value range depends on the current output unit of the calculate block's measured
value, as shown in table 6-10 Value ranges, depending on the unit.
Parameters:
<value> float_value
*RST: 0 DBM or 0 DB
Default unit: See table referred to above.
CALCulate<[1]..8>:RELative[:MAGNitude]:AUTO <auto>
Sets the current measured value as the reference value. When used as a setting com-
mand, this command can only be called by the parameter ONCE. OFF will be ignored.
OFF is always returned in response to a query.
Error messages:
-230 "Data corrupt or stale": The current measured value is invalid.
Parameters:
<auto> OFF | ONCE
*RST: OFF
CALCulate<[1]..8>:RELative:POWer[:MAGNitude] <value>
Has the same direct effect as CALC:REL on the reference value for measured values
that share the unit of a power.
Parameters:
<value> float_value, units: DBM | W
Range: 1e-18..1e18 W | -150..210 DBM
*RST: 0 DBM
Default unit: DBM
CALCulate (Configuration of Calculate Blocks)
