R&S NRP2 - Page 261

Remote Control - Commands
R&S
®
NRP2
243User Manual 1173.9157.02 ─ 03
Parameters:
<upper_limit> float_value
*RST: 30 DBM
Default unit: DBM
DISPlay[:WINDow]<[1]..4>:METer:UPPer:RATio <upper_limit>
DISPlay[:WINDow]<[1]..4>:ANALog:UPPer:RATio <upper_limit>
Sets the upper limit value of the analog scale. This value is used if the unit of the mea-
surement result is dB, percent or the number 1, i.e. the measurement result is a power
ratio.
Value range: See table 6-10 Value ranges, depending on the unit.
Unit: DB | DPCT | O
Parameters:
<upper_limit> float_value
*RST: 60 DB
Default unit: DB
DISPlay[:WINDow]<[1]..4>:NAME <string>
Determines the string to be displayed in the titlebar of the respective window. The reset
values depend on the window (<n> = 1, 2, 3 or 4).
Parameters:
<string> string
*RST: " "
Example:
DISP1:NAME "Power In"
DISP2:NAME "Power Out"
The measured values in the display are now visually assigned to
the different test points in the test setup. (Input power in window
1, output power in window 2).
DISPlay[:WINDow]<[1]..4>:RESolution <resolution>
Specifies the number of significant places of the mantissa when the measurement result
is displayed on a linear scale. The R&S NRP2 tries to adjust the averaging filter range
so that the display noise decreases with increasing resolution. The values of the transfer
parameter have the following meaning:
Parameter Linear scale of measurement result Logarithmic scale of measurement
result
1 1 significant place No decimal place
0.1 2 significant places 1 decimal place
0.01 3 significant places 2 decimal places
0.001 4 significant places 3 decimal places
DISPlay
