R&S NRP2 - Page 263

Remote Control - Commands
R&S
®
NRP2
245User Manual 1173.9157.02 ─ 03
Parameters:
<window_size> NORMal | ZOOMed
NORMal
The window size is determined automatically and depends on the
total number of open windows.
ZOOMed
The selected window (DISP:WIND:SEL[?]) is set to maximum
size, regardless of the the number of visible windows. All other
open windows are covered.
*RST: NORMal
DISPlay[:
WINDow]<[1]..4>[:STATe] <state>
Opens or closes a window. When a window is closed the other windows are automatically
expanded so that the free space is utilized. Likewise, open windows become smaller
when a new one is opened.
Parameters:
<state> ON | OFF
*RST: ON (Window 1) | OFF (Window 2,3,4)
DISPlay[:WINDow]<[1]..4>:TRACe:LOWer <lower_limit>
Sets the lower limit for the power axis in the Trace mode. The value range depends on
the unit.
Table 6-13: The value range depends on the unit
Unit of measured value W DBM DBUV
Value range -999.999E3
..
999.999E3
-120
..
90
-13.010
..
136.990
Unit: DBM | W | DBUV
Parameters:
<lower_limit> float_value
*RST: - 120 DB
Default unit: DBM
DISPlay[:WINDow]<[1]..4>:TRACe:UPPer <upper_limit>
Sets the upper limit for the power axis in the Trace mode.
Value range: See table 6-13 The value range depends on the unit.
Unit: DBM | W | DBUV
DISPlay
