Remote Control - Commands
R&S
®
NRP2
267User Manual 1173.9157.02 ─ 03
[SENSe<[1]..4>]:CORRection:FDOFfset[:INPut][:MAGNitude]?
Queries the frequency dependent offset. The frequency-dependent measured-value cor-
rection is set by selecting a table with the
[SENSe<[1]..4>]:CORRection:FDOTable[:SELect] and
[SENSe<[1]..4>]:CORRection:FDOTable:STATe ON commands. The respective
frequency-dependent correction factor is determined by means of the active tables (if
necessary by interpolation) and can be queried with
[SENSe<[1]..4>]:CORRection:FDOFfset[:INPut][:MAGNitude]? (fre-
quency-dependent offset).
Unit: DB
Usage:
Query only
[SENSe<[1]..4>]:CORRection:FDOTable[:SELect] <table_name>
The name of the current frequency-dependent offset table can be set or queried by the
[SENSe<[1]..4>]:CORRection:FDOTable[:SELect][?] command. The
R&S NRP2 can manage up to ten tables (MEMory commands). The frequency-dependent
offset tables consist of two columns; the first containing the frequencies, the second the
associated correction values. When the R&S NRP2 is informed about the signal fre-
quency with command [SENSe<[1]..4>]:FREQuency[:CW|:FIXed]
<float_value>, an appropriate correction factor is determined by means of the table.
If the table was activated with
[SENSe<[1]..4>]:CORRection:FDOTable:STATe[?] ON , the measurement
result obtained by the sensor is multiplied by this factor.
Error messages:
-256 "File name not found": An invalid <string> parameter was transmitted.
Parameters:
<table_name> string
*RST: Settings are not changed in case of *RST.
[SENSe<[1]..4>]:CORRection:FDOTable:STATe <state>
Activates and deactivates the current frequency-dependent offset table. The current table
is selected with the [SENSe<[1]..4>]:CORRection:FDOTable[:SELect] com-
mand. Only one table can be active at a time.
Parameters:
<state> ON | OFF
*RST: OFF
[SENSe<[1]..4>]:CORRection:SPDevice:SELect <NR1>
Several S-parameter tables can be stored in a sensor.
SENSe (Sensor Commands)
