[SENSe<[1]..4>]:TRACe:MEASurement:TRANSition:POSitive:OCCurrence?
Returns the start point of the current pulse, i.e. the time when the signal passes through
the medial reference level with rising edge. The medial level can be adjusted using the
command SENS:TRAC:MEAS:DEF:DUR:REF.
Usage: Query only
[SENSe<[1]..4>]:TRACe:MEASurement:TRANSition:POSitive:OVERshoot?
Returns the amount of relative undershooting of the signal at the beginning of a pulse.
Usage: Query only
[SENSe<[1]..4>]:TRACe:MEASurement:TRANSition:SPERiod?
Usage:
Query only
[SENSe<[1]..4>]:TRACe:MEASurement[:STATe] <state>
Switches on/off automatic pulse measurements in the Trace mode. If pulse measurement
is on, the sensor automatically determines the pulse parameters for the currently mea-
sured trace. For pulse measurements, also set SENS:TRAC:MEAS:AUTO ON.
Parameters:
<state> ON | OFF
*RST: depending on the sensor
[SENSe<[1]..4>]:TRACe:OFFSet:TIME <time>
Determines the relative position of the trigger event in relation to the beginning of the
Trace measurement sequence.
Parameters:
<time> float_value
Range: depending on sensor
*RST: depending on sensor
Default unit: S
[SENSe<[1]..4>]:TRACe:POINts <points>
Sets the number of desired values per Trace sequence.
Error messages:
28 "Sensor not idle": The sensor is not in the IDLE state.
