R&S NRP2 - Page 306

Remote Control - Commands
R&S
®
NRP2
288User Manual 1173.9157.02 ─ 03
[SENSe<[1]..4>]:TRACe:MEASurement:PULSe:SEParation?
Returns the time from "Stop Time" to "Start Time" of the first detected pulse.
Usage: Query only
[SENSe<[1]..4>]:TRACe:MEASurement:TIME <time>
Parameters:
<time> float_value
Range: depending on the sensor
*RST: depending on the sensor
Default unit: S
[
SENSe<[1]..4>]:TRACe:MEASurement:TRANSition:ESAMpling:AUTO[:STATe]?
Usage:
Query only
[SENSe<[1]..4>]:TRACe:MEASurement:TRANSition:NEGative:DURation?
Returns the fall time of the first detected pulse. The fall time is the time the signal requires
to change from high to low level. High and low levels can be adjusted using the commands
SENS:TRAC:MEAS:DEF:TRAN:HREF and SENS:TRAC:MEAS:DEF:TRAN:LREF.
Usage:
Query only
[SENSe<[1]..4>]:TRACe:MEASurement:TRANSition:NEGative:OCCurrence?
Returns the stop point of the current pulse, i.e. the time when the signal passes through
the medial reference level with falling edge. The medial level can be adjusted using the
command SENS:TRAC:MEAS:DEF:DUR:REF.
Usage:
Query only
[SENSe<[1]..4>]:TRACe:MEASurement:TRANSition:NEGative:OVERshoot?
Returns the amount of relative undershooting of the signal at the end of a pulse.
Usage:
Query only
[SENSe<[1]..4>]:TRACe:MEASurement:TRANSition:POSitive:DURation?
Returns the rise time of the first detected pulse. The rise time is the time the signal
requires to change from low to high level. High and low levels can be adjusted using the
commands SENS:TRAC:MEAS:DEF:TRAN:HREF and
SENS:TRAC:MEAS:DEF:TRAN:LREF.
Usage:
Query only
SENSe (Sensor Commands)
