Remote Control - Commands
R&S
®
NRP2
305User Manual 1173.9157.02 ─ 03
Bit No. Meaning
5 Operation Trigger Status Register summary bit
This bit is set if a sensor is in the WAIT_FOR_TRG state, i.e. waiting for a trigger event.
6 Not used
7 to 9 Not used
10 Operation Sense Status Register summary bit
This bit is set if a sensor is initialized.
11 Operation Lower Limit Fail Status Register
This bit is set if a displayed value has dropped below a lower limit value.
12 Operation Upper Limit Fail Status Register
This bit is set if a displayed value has exceeded an upper limit value.
13 to 14 Not used
15 Bit 15 will never be used.
6.13.11 Operation Calibrating Status Register
The CONDition register contains information as to whether a sensor is currently being
calibrated and, depending on the configuration of the transition register, the EVENt reg-
ister indicates whether a calibration was started or completed since the last readout of
this register. The Operation Calibration Status Register can be read by the following
commands:
STATus:OPERation:CALibrating[:SUMMary]:CONDition?
STATus:OPERation:CALibrating[:SUMMary][:EVENt]? .
Table 6-23: Meaning of bits used in the Operation Calibrating Status Register
Bit No. Meaning
0 Not used
1 Sensor A is being calibrated
2 Sensor B is being calibrated
3 Sensor C is being calibrated
4 Sensor D is being calibrated
5 to 14 Not used
15 Bit 15 will never be used.
6.13.12 Operation Measuring Status Register
The CONDition register contains information as to whether a measurement is being per-
formed by a sensor and, depending on the configuration of the transition register, the
STATus
