EVENt register indicates whether a measurement was started or completed since the last
readout of this register.
The Operation Measuring Status Register can be read by the following commands:
STATus:OPERation:MEASuring[:SUMMary]:CONDition?
STATus:OPERation:MEASuring[:SUMMary][:EVENt]?.
Table 6-24: Meaning of bits used in the Operation Measuring Status Register
Bit No. Meaning
0 Not used
1 Sensor A measuring
Sensor A is performing a measurement.
2 Sensor B measuring
Sensor B is performing a measurement.
3 Sensor C measuring
Sensor C is performing a measurement.
4 Sensor D measuring
Sensor D is performing a measurement.
5 to14 Not used
15 Bit 15 will never be used.
6.13.13 Operation Trigger Status Register
The CONDition register contains information as to whether a sensor is currently in the
WAIT_FOR_TRG state, i.e. expecting a trigger event and, depending on the configuration
of the transition register, the EVENt register indicates whether the WAIT_FOR_TRG state
was entered or quit by a sensor since the last readout of the register.
The Operation Trigger Status Register can be read by the following commands:
STATus:OPERation:TRIGger[:SUMMary]:CONDition?
STATus:OPERation:TRIGger[:SUMMary][:EVENt]? .
Table 6-25: Meaning of bits used in the Operation Status Register
Bit No. Meaning
0 Not used
1 Sensor A waiting for trigger
Sensor A is in the WAIT_FOR_TRG state and is waiting for a trigger event that will change it
to the MEASURING state.
2 Sensor B waiting for trigger
Sensor B is in the WAIT_FOR_TRG state and is waiting for a trigger event that will change it
to the MEASURING state.
