MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 10/07/2020 • Rev.38 13
PRODUCT COMPOSITION
The MOSAIC M1 and M1S are supplied with:
• CD-ROM containing the free MSD SW, the present PDF multi-language handbook
and other product literature.
• Multi-language installation sheet.

NB: the rear panel MSC connector and MCM memory can be ordered separately as
accessories.
The expansion units are supplied with:
• Multilingual Installation sheet.
• Rear panel MSC connector (not present in the MR2 and MR4 which are connected
via terminal blocks only).

NB: to install an expansion unit (excluding relays) you will need the MSC connector
supplied with the unit plus another MSC for the connection to the M1 or M1S.
This can be ordered separately as an accessory.
