Module MOR4
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
2
NODE_SEL0
Input
Node selection
Input ("type B" according to EN 61131-2)
3
NODE_SEL1
Input
Input ("type B" according to EN 61131-2)
4
0VDC
-
0VDC power supply
-
5
REST_FBK1
Input
Feedback/Restart 1
Input (according EN 61131-2)
6
REST_FBK2
Input
Feedback/Restart 2
Input (according EN 61131-2)
7
REST_FBK3
Input
Feedback/Restart 3
Input (according EN 61131-2)
8
REST_FBK4
Input
Feedback/Restart 4
Input (according EN 61131-2)
9
A_NO1
Output
N.O. contact Channel 1
10
B_NO1
Output
11
A_NO2
Output
N.O. contact Channel 2
12
B_NO2
Output
13
A_NO3
Output
N.O. contact Channel 3
14
B_NO3
Output
15
A_NO4
Output
N.O. contact Channel 4
16
B_NO4
Output
Table 16
Module MOR4S8
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
2
NODE_SEL0
Input
Node selection
Input ("type B" according to EN 61131-2)
3
NODE_SEL1
Input
Input ("type B" according to EN 61131-2)
4
0VDC
-
0VDC power supply
-
5
REST_FBK1
Input
Feedback/Restart 1
Input (according EN 61131-2)
6
REST_FBK2
Input
Feedback/Restart 2
Input (according EN 61131-2)
7
REST_FBK3
Input
Feedback/Restart 3
Input (according EN 61131-2)
8
REST_FBK4
Input
Feedback/Restart 4
Input (according EN 61131-2)
9
A_NO1
Output
N.O. contact Channel 1
10
B_NO1
Output
11
A_NO2
Output
N.O. contact Channel 2
12
B_NO2
Output
13
A_NO3
Output
N.O. contact Channel 3
14
B_NO3
Output
15
A_NO4
Output
N.O. contact Channel 4
16
B_NO4
Output
17
OUT_STATUS1
Output
SIL 1/PL c
PNP active high
18
OUT_STATUS2
Output
SIL 1/PL c
PNP active high
19
OUT_STATUS3
Output
SIL 1/PL c
PNP active high
20
OUT_STATUS4
Output
SIL 1/PL c
PNP active high
21
OUT_STATUS5
Output
SIL 1/PL c
PNP active high
22
OUT_STATUS6
Output
SIL 1/PL c
PNP active high
23
OUT_STATUS7
Output
SIL 1/PL c
PNP active high
24
OUT_STATUS8
Output
SIL 1/PL c
PNP active high
Table 17
