MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 10/07/2020 • Rev.38 47
Response time M1S (ms)
This response times depends on the following
parameters:
1) Number of Slave modules installed
2) Number of Operators
3) Number of OSSD outputs
For the right response time refer to the one
calculated by the DSD software (see Project report)
Failure Response time M1S (ms)
This parameter corresponds to the response time,
with the exception of MV modules with
Encoder/Proximity interface where is 2s
M1 / M1S -> module connection
ReeR proprietary 5-pole bus (MSC)
Connection cable cross-section
0,5 ÷ 2,5 mm
2
/ AWG 12÷30 (solid/stranded)
Max length of connections
Max surrounding air temperature
Max. altitude (above sea level)

T
Input_filter
= max filtering time from among those set on project inputs
(see "INPUTS" section").
Enclosure
Electronic housing max 24 pole, with locking latch mounting
Enclosure protection class
Terminal blocks protection class
Quick coupling to rail according to EN 60715
M1 module
Unit enable (No./description)
2 / PNP active high "type B" according to EN 61131-2
Digital INPUTS (No./description)
8 / PNP active high according to EN 61131-2
INPUT FBK/RESTART (No./description)
2 / EDM control / possible Automatic
or Manual operation with RESTART button
Test OUTPUT (No./description)
4 / to check for short-circuits - overloads
SIL 1/PL c OUTPUTS (No./description)
2 / programmable - PNP active high
2 pairs / solid state safety outputs PNP active high
400mA@24VDC max - Interface type C class 3 (ZVEI CB24I)
USB 2.0 (Hi Speed) - Max cable length: 3m
Connection to slave units
via MSC 5-way ReeR proprietary bus
