MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 10/07/2020 • Rev.38 77
MI12T8 (Figure 39)
Shows the physical
address of the unit
Return the unit to ReeR to be repaired
• Firmware version not compatible with M1,
return to ReeR for FW upgrade.
Error in communication with
master
• Restart the system
• If the problem persists, return the unit to
ReeR to be repaired
Error on other
slave or M1
• Restart the system
• Check which unit is in FAIL mode
Same type of slave with
same address detected
• Change the unit's address (see NODE SEL)
Node detection circuit error
• Return the unit to ReeR to be repaired
Table 69 - Troubleshooting MI12T8
