Reer MOSAIC MI8O4C Installation And Use

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 10/07/2020 • Rev.38 51
English
MO4LHCS8 module
PFH
d
(IEC 61508:2010)
8,64E-09
Rated voltage
24VDC ± 20%
Dissipated power max
4W max
OSSD output current
2A max per channel *
Number of Safety Outputs (OSSD)
4 single channels (or 2 dual channels), cat.4
Interface type C class 3 (ZVEI CB24I)
INPUT FBK/RESTART (No./description)
4 / EDM control / possible Automatic
or Manual operation with RESTART button
Digital OUTPUT (No./description)
SIL 1/PL c 8 / Programmable output / PNP active high
Response time
12ms
Connection to M1 and M1S
via MSC 5-way ReeR proprietary bus

Using MO4LHCS8 with current output >500mA, separate it from adjacent modules by
interposing an MSC connector.
MV0 - MV1 - MV2 modules
Condition
(-> SPEED CONTROL TYPE FUNCTION BLOCKS)
Overspeed
Stand still
Window speed
Safe state
Overspeed
NO Stand still
Out of Window speed
Model
MV0
MV1
MV2
PFH
d
7,36E-09
-
-
PFH
d
(TTL)
-
8,46E-09 (MV1T)
9,56E-09 (MV2T)
PFH
d
(sin/cos)
-
9,31E-09 (MV1S)
1,13E-08 (MV2S)
PFH
d
(HTL24)
-
8,08E-09 (MV1H)
8,80E-09 (MV2H)
PFH
d
(TTL internal power supply)
-
9,20E-09 (MV1TB)
1,10E-08 (MV2TB)
Rated Voltage
24VDC ± 20%
Dissipated power max
3W
Input impedance
-
120 Ohm (MV1T MV1TB / MV2T MV2TB models)
120 Ohm (MV1S - MV2S models)
Encoder Interface
-
TTL (MV1T MV1TB / MV2T MV2TB models)
HTL (MV1H - MV2H models)
sin/cos (MV1S - MV2S models)
Encoder connections
-
RJ45 connector
Encoder input signals electrically
insulated in accordance with
EN 61800-5
-
Rated insulation voltage 250V
Overvoltage category II
Rated impulse withstand voltage 4.00 kV
Max number of encoders
-
1
2
Max encoder frequency
-
500kHz (HTL: 300kHz)
Encoder adjustable threshold range
-
1Hz ÷ 450kHz
Proximity type
PNP/NPN - 3/4 wires
Proximity connections
Terminal blocks
Proximity adjustable threshold range
1Hz ÷ 4kHz
Max number of proximity
2
Max proximity frequency
5kHz
Max number of axes
2
Stand-still/overspeed frequency gap
>10Hz
Min. gap between thresholds
(with thresholds >1)
> 5%
M1 connections and M1S
via MSC 5-way ReeR proprietary bus
