Reer MOSAIC MI8O4C Installation And Use

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
16 8540780 • 10/07/2020 • Rev.38
English
Instructions concerning connection cables.

Wire size range: AWG 12÷30, (solid/stranded) (UL).

Use 60/75°C copper (Cu) conductor only.

We recommend the use of separate power supplies for the safety module and for other
electrical power equipment (electric motors, inverters, frequency converters) or other
sources of disturbance.

Cables used for connections of longer than 50m must have a cross-section of at least
1mm
2
(AWG16).
Connections of each single MOSAIC system unit are listed in the table below:
Master Module M1
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
2
MASTER_ENABLE1
Input
Master Enable 1
Input ("type B" according to
EN 61131-2 )
3
MASTER_ENABLE2
Input
Master Enable 2
Input ("type B" according to
EN 61131-2 )
4
0VDC
-
0VDC power supply
-
5
OSSD1_A
Output
Static output 1
PNP active high
6
OSSD1_B
Output
PNP active high
7
RESTART_FBK1
Input
Feedback/Restart 1
Input according to EN 61131-2
8
OUT_STATUS1
Output
SIL 1/PL c output
PNP active high
9
OSSD2_A
Output
Static output 2
PNP active high
10
OSSD2_B
Output
PNP active high
11
RESTART_FBK2
Input
Feedback/Restart 2
Input according to EN 61131-2
12
OUT_STATUS2
Output
SIL 1/PL c output
PNP active high
13
OUT_TEST1
Output
Short circuit detection output
PNP active high
14
OUT_TEST2
Output
Short circuit detection output
PNP active high
15
OUT_TEST3
Output
Short circuit detection output
PNP active high
16
OUT_TEST4
Output
Short circuit detection output
PNP active high
17
INPUT1
Input
Digital input 1
Input according to EN 61131-2
18
INPUT2
Input
Digital input 2
Input according to EN 61131-2
19
INPUT3
Input
Digital input 3
Input according to EN 61131-2
20
INPUT4
Input
Digital input 4
Input according to EN 61131-2
21
INPUT5
Input
Digital input 5
Input according to EN 61131-2
22
INPUT6
Input
Digital input 6
Input according to EN 61131-2
23
INPUT7
Input
Digital input 7
Input according to EN 61131-2
24
INPUT8
Input
Digital input 8
Input according to EN 61131-2
