Reer MOSAIC MI8O4C Installation And Use

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8 8540780 • 10/07/2020 • Rev.38
English
INTRODUCTION
Contents of this handbook
This handbook describes how to use the MOSAIC programmable safety module and its
expansion units ("SLAVES");
it includes:
• a description of the system
• method of installation
• connections
• signals
• troubleshooting
• use of the configuration SW
Important safety instructions
 This safety alert symbol indicates a potential personal safety hazard. Failure to comply with
instructions bearing this symbol could pose a very serious risk to personnel.

This symbol indicates an important instruction.
 The MOSAIC is built to the following safety levels: SIL 3, SILCL 3, PL e, Cat. 4, Type 4 in
accordance with the applicable standards. However, the definitive SIL and PL of the application
will depend on the number of safety components, their parameters and the connections that
are made, as per the risk analysis.
 Read the "Applicable Standards" section carefully.
 Perform an in-depth risk analysis to determine the appropriate safety level for your specific
application, on the basis of all the applicable standards.
 Programming/configuration of the Mosaic is the sole responsibility of the installer or user.
 The device must be programmed/configured in accordance with the application-specific risk
analysis and all the applicable standards.
 Once you have programmed/configured and installed the Mosaic and all the relative devices,
run a complete application safety test (see the "TESTING the system" section, page 106).
 Always test the complete system whenever new safety components are added (see the
"TESTING the system" page 106).
 ReeR is not responsible for these operations or any risks in connection therewith.
 Reference should be made to the handbooks and the relative product and/or application
standards to ensure correct use of devices connected to the Mosaic within the specific
application.
 The ambient temperature in the place where the system is installed must be compatible with
the operating temperature parameters stated on the product label and in the specifications.
 For all matters concerning safety, if necessary, contact your country's competent safety
authorities or the competent trade association.
