Reer MOSAIC MI8O4C Installation And Use

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 10/07/2020 • Rev.38 31
English
Modulo MA4
PIN
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24 VDC
-
24VDC power supply
-
2
NODE_SEL0
Input
Node selection
Input ("type B" according to EN 61131-2)
3
NODE_SEL1
Input
Input ("type B" according to EN 61131-2)
4
0 VDC
-
0VDC power supply
-
9
24VDC_S1
Output
Sensor 1 Connections
Isolated 24VDC power supply for sensor 1
10
IN_S1
Input
4/20mA sensor 1 Input
NEG_S1
Input
0/10V sensor 1 negative input
11
OUT_S1
Output
4/20mA sensor 1 Output
POS_S1
Input
0/10V sensor 1 positive input
12
0 VDC_S1
Output
Isolated 0VDC reference for sensor 1
13
24VDC_S3
Output
Sensor 3 Connections
Isolated 24VDC power supply for sensor 3
14
IN_S3
Input
4/20mA sensor 3 Input
NEG_S3
Input
0/10V sensor 3 negative input
15
OUT_S3
Output
4/20mA sensor 3 Output
POS_S3
Input
0/10V sensor 3 positive input
16
0 VDC_S3
Output
Isolated 0VDC reference for sensor 3
17
24VDC_S2
Output
Sensor 2 Connections
Isolated 24VDC power supply for sensor 2
18
IN_S2
Input
4/20mA sensor 2 Input
NEG_S2
Input
0/10V sensor 2 negative input
19
OUT_S2
Output
4/20mA sensor 2 Output
POS_S2
Input
0/10V sensor 2 positive input
20
0 VDC_S2
Output
Isolated 0VDC reference for sensor 2
21
24VDC_S4
Output
Sensor 4 Connections
Isolated 24VDC power supply for sensor 4
22
IN_S4
Input
4/20mA sensor 4 Input
NEG_S4
Input
0/10V sensor 4 negative input
23
OUT_S4
Output
4/20mA sensor 4 Output
POS_S4
Input
0/10V sensor 4 positive input
24
0 VDC_S4
Output
Isolated 0VDC reference for sensor 4
Table 22
