MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 10/07/2020 • Rev.38 49
English
MI8 - MI16 modules
Model
MI8
MI16
PFH
d
(IEC 61508:2010)
4.46E-9
4.93E-9
Rated voltage
24VDC  20%
Dissipated power
3W max
Digital INPUTS (No./description)
8
16
PNP active high according to EN 61131-2
Test OUTPUT (No./description)
4 / to check for short-circuits - overloads
Connection to M1 and M1S
via MSC 5-way ReeR proprietary bus
MI12T8 module
PFH
d
(IEC 61508:2010)
5,60E-09
Rated voltage
24VDC  20%
Dissipated power
3W max
Digital INPUTS (No./description)
12
PNP active high according to EN 61131-2
Test OUTPUT (No./description)
8 / to check for short-circuits - overloads
Connection to M1 and M1S
via MSC 5-way ReeR proprietary bus
MO2 - MO4 modules
Model
MO2
MO4
PFHd (IEC 61508:2010)
4,08E-09
5,83E-09
Rated voltage
24VDC  20%
Dissipated power
3W max
INPUT FBK/RESTART (No./description)
2 4 / EDM control / possible Automatic
or Manual operation with RESTART button
SIL 1/PL c OUTPUTS (No./description)
2
4
programmable - PNP active high
OSSD (No./description)
2
4
Solid state safety outputs: PNP active high 400mA@24VDC max
Interface type C class 3 (ZVEI CB24I)
Connection to M1 and M1S
via MSC 5-way ReeR proprietary bus
MO4L module
PFH
d
(IEC 61508:2010)
1,12E-08
Rated voltage
24VDC  20%
Dissipated power
3W max
INPUT FBK/RESTART (No./description)
Up to 4 / EDM control / possible Automatic
or Manual operation with RESTART button
SIL 1/PL c OUTPUTS (No./description)
4 / programmable - PNP active high
OSSD (No./description)
4 single / solid state safety outputs: PNP active high
400mA@24VDC max - Interface type C class 3 (ZVEI CB24I)
Connection to M1S
via MSC 5-way ReeR proprietary bus
