MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
78 8540780 • 10/07/2020 • Rev.38
MI16 (Figure 40)
Shows the
physical
address of the
unit
• Return the unit to ReeR to be repaired
• Firmware version not compatible with M1,
return to ReeR for FW upgrade.
Error in communication with
master
• Restart the system
• If the problem persists, return the unit to
ReeR to be repaired
Error on other
slave or M1
• Restart the system
• Check which unit is in FAIL mode
Same type of slave with same
address detected
• Change the unit's address (see NODE SEL)
Node detection circuit error
• Return the unit to ReeR to be repaired
Table 70 - Troubleshooting MI16
