MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
146 8540780 • 10/07/2020 • Rev.38
Detailed description
Input type
It defines the inputs type of the MA2/MA4 module channels described below.
Single
A single sensor is connected to one channel from 1 to 4.
Redundant
A pair of sensors is connected to two adjacent channels (1-2 or 3-4). The sensor
pair readings are processed by a single analog block.
In the table below are summarized the channels allowable connections (the
Not-connected cases are excluded on purpose).
