Reer MOSAIC MI8O4C Installation And Use

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
150 8540780 • 10/07/2020 • Rev.38
English
Input Type Redundant: Consolidation
If you select Redundant as Input type, you must configure the
Consolidation parameter which specifies the measurement value
to be used.
Select the measurement values to be used by MA2/MA4
comparators and sent as analog data to M1S controller:
 Input Ain: Use the values supplied by the connected Channel.
 AinR: Use the values supplied by the connected Channel.
 Maximum: Use the maximum value supplied by channels 1 or 2,
whichever is greater.
 Minimum: Use the minimum value supplied by channels 1 or 2, whichever is less.
 Arithmetic average: Use the arithmetic mean of the values supplied by channels 1 and 2.

Reer MOSAIC MI8O4C Specifications

General

Brand	Reer
Model	MOSAIC MI8O4C
Category	Controller
Language	English
