Renesas M16C/29 Series - Page 348

19. Programmable I/O Ports
puorG92/C61M
page 322
854fo7002,03.raM21.1.veR
2110-1010B90JER
Figure 19.5 I/O Pins
CNVSS
CNVSS signal input
RESET
RESET signal input
(1)
(1)
NOTE:
1. symbolizes a parasitic diode.
Make sure the input voltage on each port will not exceed Vcc.
